Responsible Monetization of Geolocation Information
The GMLC & E-SMLC enable mobile operators to support public safety alerts, complement marketing efforts with a geographically relevant perspective, provide IoT asset tracking information, and deliver accurate location based services (LBS) for personal security and authentication use cases.
Mobile operators hold one of the most powerful assets in digital services: location data, yet they often struggle to monetize it safely and efficiently. With PAiCore’s GMLC & E-SMLC, operators stay in full control of how geolocation data is used and shared.
PAiCore’s GMLC provides Cell ID information from any 2G/3G/4G/5G network, and has the ability to enable access to this information in an anonymous & secure way when queried for a particular device or mobile number via our Geolocation API.
The E-SMLC & the LMF (for 5G) provide increased accuracy as complement to the GMLC, reaching precisions levels comparable to GPS location methods, but without the transactional costs or battery drain associated to these type of transactions.
Key Features of PAiCore-as-a-Service GMLC & E-SMLC
- Its open source nature enables continuous innovation and use case adaptation from both our team and the contributions of the open source user.
- SUPL (Secure User Plane Location) geolocation capabilities are supported for improved accuracy.
- High-availability deployments supported in either active-active or active-passive modes.
- Its multi-protocol nature allows retrieving location information from 2G, 3G and 4G LTE.
Main Benefits of GMLC & E-SMLC Core Technologies (CT) Edition
High accuracy, comparable to GPS, thanks to E-SMLC & LMF
Real time configuration & alerts for geofences
Integration with third-party apps through geolocation APIs
PAiCore Technologies GMLC & E-SMLC Versions
| Feature | Free Basic Version | PAiCore-as-a-Service | CT Edition |
|---|---|---|---|
| Network Technologies | |||
| 2G: GERAN (GSM EDGE Radio Access Network) | ✓ | ✓ | ✓ |
| 3G: UTRAN (Universal Terrestrial Radio Access Network) | ✓ | ✓ | ✓ |
| 4G: E-UTRAN (Evolved Universal Terrestrial Radio Access Network) | — | ✓ | ✓ |
| 5G: NR (New Radio) | — | — | ✓ |
| Service Mobile Location Centre (E-SMLC, 2026) | — | — | ✓ |
| Standards Compliance & Protocols | |||
| Diameter | |||
Diameter Routing Information Request/Answer (RIR/RIA) |
✓ | ✓ | ✓ |
ELP Provide Location Request/Answer (PLR/PLA) |
✓ | ✓ | ✓ |
ELP Location Report Request/Answer (LRR/LRA) |
✓ | ✓ | ✓ |
Sh User-Data-Request/Answer (UDR/UDA) |
✓ | ✓ | ✓ |
Diameter SLh compliant with 3GPP TS 29.172 v18.0.0 |
— | ✓ | ✓ |
Diameter SLg compliant with 3GPP TS 29.172 v18.1.0 |
— | ✓ | ✓ |
| SS7 | |||
MAP Any-Time-Interrogation (ATI) |
✓ | ✓ | ✓ |
MAP Provide-Subscriber-Information (PSI) |
✓ | ✓ | ✓ |
MAP Send Routing Information for Location Services (SRILCS) |
✓ | ✓ | ✓ |
MAP Provide Subscriber Location (PSL) |
✓ | ✓ | ✓ |
MAP Subscriber Location Report (SLR) |
✓ | ✓ | ✓ |
MAP Interface compliant with 3GPP TS 29.002 v18.0.0 |
— | ✓ | ✓ |
| Secure User Plane Location | |||
MLP |
— | ✓ | ✓ |
HTTP |
— | ✓ | ✓ |
SUPL INIT |
— | ✓ | ✓ |
SUPL POS INIT |
— | ✓ | ✓ |
SUPL POS |
— | ✓ | ✓ |
SUPL END |
— | ✓ | ✓ |
SUPL TRIGGERED START |
— | — | ✓ |
SUPL TRIGGERED RESPONSE |
— | — | ✓ |
SUPL TRIGGERED STOP |
— | — | ✓ |
SUPL RESPONSE |
— | — | ✓ |
SUPL REPORT |
— | — | ✓ |
HTTP/2 |
— | — | ✓ |
| Reliability | |||
| High availability | — | — | ✓ |
| Containerized deployment | |||
| Docker | — | — | ✓ |
| Kubernetes | — | — | ✓ |
| Graphical User Interface | |||
| User and Permissions Management | — | — | ✓ |
| User Groups Management | — | — | ✓ |
| Dashboard | — | — | ✓ |
Query Statistics |
— | — | ✓ |
Tracking Statistics |
— | — | ✓ |
| Tracking Functionalities (Map Visualization) | — | — | ✓ |
Ad-hoc Queries |
— | — | ✓ |
Automated Tracking |
— | — | ✓ |
Movement Plotting on Map |
— | — | ✓ |
| Geofencing | — | — | ✓ |
Geofence Creation and Management |
— | — | ✓ |
Geofence Alerts |
— | — | ✓ |
Geofence Groups |
— | — | ✓ |
GMLC & E-SMLC Product Brief
GMLC version 6.0.0 Release Notes
Built-In GUI for Geolocation Management
GMLC open source and ready to use
Request a Free License
Contact us for access to a free license for the Free Basic Version of our products and discover their features.
