Messaging Open Source v3.3.0

Modernize Messaging. Take Control of Delivery. SMSC for Legacy, LTE & IMS. SMSF for 5G Standalone.

PAiCore's open-source SMSC brings multi-protocol messaging, configurable delivery retries and online charging into one platform. Connect legacy, LTE and IMS networks, then extend SMS services to 5G Standalone with the complementary PAiCore SMSF module.

OVERVIEW

PAiCore's open-source SMSC helps operators modernize messaging infrastructure with flexible routing and interworking across SMPP, HTTP, SS7/SIGTRAN and Diameter. Integrated IP-SM-GW functionality also bridges SIP-based IMS and legacy networks, supporting SMS service continuity as mobile networks evolve.

SMSC v3.3.0 gives operators greater control over delivery through configurable Retry Profiles, alternative routing and multipart retry policies. New Diameter ECUR online charging complements IEC, allowing units to be reserved before delivery and committed or released according to the final delivery result.

The platform supports high-availability and geo-redundant deployments, with processing capacity of up to 100,000 TPS for SMPP, corresponding to approximately 12,500 messages per second in the documented flow. Actual throughput depends on the protocol, infrastructure and deployment configuration.

Secure connectivity includes SMPP over TLS and HTTP authentication using Basic, Bearer Token or API Key. Flexible commercial options include the open-source Basic Version, professional services and 24/7 technical support under the applicable support plan.

KEY FEATURES

  • High-Throughput Messaging

    Up to 100,000 SMPP transactions per second, with capacity sized for the protocol and deployment.

  • Legacy, LTE & IMS Interworking

    Connect SMPP, HTTP, SS7/MAP and Diameter, with integrated IP-SM-GW support for SIP-based IMS networks.

  • Intelligent Retry Management

    Configure retry schedules, recovery profiles, alternative destinations and multipart retry behavior.

  • Delivery-Aware Online Charging

    Integrate with an OCS using Diameter ECUR or IEC, with reservation handling for multipart messages and retries.

  • Secure Connectivity & Access

    Protect integrations with SMPP over TLS, HTTP authentication and secure token lifecycle management.

  • Operational Visibility & Resilience

    Trace retry policies in CDRs, filter reports by DLR status and deploy with high availability and geo-redundancy.

Applications

SMPP & HTTP

Reliable HTTP and SMPP to SS7 conversion, with SMPP over TLS and SMPP and HTTP Proxy Mode.

SMSC
2G / 3G

SS7/SIGTRAN

Flexible realtime SS7 parameter control via GUI or APIs.

SMSC
4G / LTE

Diameter

Diameter for 4G/LTE deployments and SMS over LTE Support.

SMSC
5G Standalone

5G Service-Based Architecture

Native SMS through the AMF and UDM over standardized service-based interfaces.

SMSF

SMSF · 5G STANDALONE

Extend Your SMSC to 5G Standalone

PAiCore SMSF complements the SMSC by enabling native SMS services within 5G Standalone networks. It connects SMS service delivery with the 5G Service-Based Architecture (SBA), extending messaging capabilities into the 5G core.

Through standardized service-based interfaces with core network functions such as the AMF and UDM, PAiCore SMSF supports Mobile-Originated and Mobile-Terminated SMS in 5G Standalone environments.

Its cloud-native, service-based design helps operators evolve their messaging infrastructure alongside their 5G deployments.

PAiCore SMSF is a complementary component of the SMSC solution.

SMSF KEY FEATURES

  • Complements the SMSC

    Extends the SMSC solution with SMS service support for 5G Standalone networks.

  • Mobile-Originated & Mobile-Terminated SMS

    Supports both directions of SMS delivery through 5G service-based interfaces.

  • Integration with the 5G Core

    Interacts with AMF and UDM through standardized service-based interfaces.

  • Cloud-Native, Service-Based Design

    Aligns SMS service deployment with the architecture of modern 5G Standalone cores.

MESSAGING CAPABILITIES

Control Every Stage of SMS Delivery

Connect networks, manage delivery policies and monetize messaging with PAiCore SMSC.

High-Throughput Messaging

Up to 100,000 SMPP TPS, equivalent to approximately 12,500 messages per second in the documented flow. Performance depends on protocol, hardware and configuration.

Multi-Protocol Interworking

Route messaging traffic across SMPP, HTTP, SS7/SIGTRAN and Diameter, including SMS over LTE through S6c and SGd.

Integrated IP-SM-GW

Bridge SIP-based IMS, SS7/MAP and Diameter with automated identity mapping, reachability subscriptions and subscriber authorization checks.

Secure Connectivity

Protect SMPP connections with TLS and secure HTTP integrations using Basic, Bearer Token or API Key authentication.

Configurable Retry Profiles

Define multi-step retry schedules, maximum retry duration and recovery profiles. Apply policies by gateway, network, protocol, error code and message conditions.

Adaptive Retry Routing

Redirect retries to alternative networks, rewrite addresses or prefixes and adjust message priority through configurable retry actions.

Multipart Delivery Control

Choose per routing rule whether to retry all message segments or only the pending parts, skipping segments already delivered.

Diameter Online Charging

Select ECUR or IEC per routing rule. ECUR reserves units before delivery and commits or releases them according to the final result, including multipart and retry handling.

Delivery Reporting & Traceability

Filter CDR reports by provider DLR status and identify the Retry Profile applied to each message for operational analysis and auditing.

Resilient Deployment Options

Support high-availability and geo-redundant deployments. Redis standalone and cluster modes accommodate different deployment sizes.

Flexible Gateway Controls

Configure SS7 delivery-status reporting and SS7/Diameter retry error classifications per gateway, alongside SMPP and HTTP Proxy Mode.

AI-Powered SMS Filtering

Integrate OpenTextShield (OTS), developed by PAiCore's strategic partner, to filter spam and phishing within the messaging flow.

USE CASES

Messaging Across Applications & Networks

Support application messaging, subscriber communications and SMS service continuity as mobile networks evolve.

Application-to-Person Messaging

Connect applications and service providers to mobile subscribers through SMPP or HTTP, with routing into telecom networks and delivery reporting.

Person-to-Person SMS

Support subscriber-to-subscriber messaging with Mobile-Originated and Mobile-Terminated SMS routing across supported network interfaces.

Business Messaging & Campaigns

Deliver B2C communications and high-volume SMS campaigns using the built-in Broadcast Campaign Manager, with configurable sender and delivery controls.

Network Modernization & SMS Continuity

Support SMS over LTE through Diameter S6c/SGd and bridge legacy and IMS networks with integrated IP-SM-GW. Complement the SMSC with PAiCore SMSF for 5G Standalone deployments.

Spam & Phishing Protection

Filter unwanted and malicious SMS within the messaging flow through integration with OpenTextShield (OTS), the AI-powered component developed by PAiCore's strategic partner.

Online Charging for SMS Services

Integrate messaging with an OCS. Diameter ECUR enables unit reservation before delivery and settlement based on the final result, including multipart messages and retries.

Feature availability depends on the selected edition and deployment. See the versions table for details.

OPEN SOURCE

Open Source Repositories

Access our open source repositories & explore how PAiCore Technology can serve your business needs. Install the Free Basic Edition and start running PAiCore SMSC in just a few minutes.

EDITIONS & FEATURES

PAiCore SMSC Editions

Compare the Free Basic Version with PAiCore SMSC v3.3.0, including advanced connectivity, security and operational features.

Feature
Free Basic Version
PAiCore SMSC v3.3.0
SMS Use Cases
Peer-to-Peer (P2P)
✓
✓
Application-to-Person (A2P)
✓
✓
Business-to-Consumer (B2C)
✓
✓
Protocols & Connectivity
SMPP
✓
✓
HTTP
✓
✓
SS7/SIGTRAN
—
✓
Diameter S6c/SGd
—
✓
SIP
—
✓
HTTP/2
—
✓
Integrations
OCS Integration via Diameter Ro
—
✓
HTTP Dynamic Payload Interpreter
—
✓
SMPP and HTTP Proxy Mode
—
✓
Reliability
Load Balancing
—
✓
High Availability
—
✓
Security & Authentication
Anti-Spam
—
✓
Anti-Fraud
—
✓
SMPP over TLS
—
✓
HTTP Authentication: Basic, Bearer Token and API Key
—
✓
AI-Powered SMS Firewall
—
✓
Core Messaging Features
SMPP Server with Multi-Port Support
✓
✓
All SMPP Bind Types: TX / RX / TRX
✓
✓
Full Data Coding Support (0–255)
✓
✓
Encodings: GSM-7, UTF-8, UCS-2 and ISO-8859-1
✓
✓
UDH Support for Concatenated and Binary SMS
✓
✓
Optional TLV Parameter Handling
✓
✓
Long Message Splitting
✓
✓
Retries & DLR Mapping
✓
✓
Message Filtering & Replacement
✓
✓
Official Docker Image
✓
✓
User Management
✓
✓
Advanced Routing & Operations
Dynamic Global Title Rewriting via Routing Rules
—
✓
Broadcast SMS
—
✓
SMS Traffic Reports & Dashboard
—
✓
Do Not Disturb
—
✓
Email-to-SMS Support
—
✓
Routing Based on Delivery Rates
—
✓
Mobile Number Portability
—
✓
SMS over LTE via Diameter S6c/SGd
—
✓
